Fluke | Digital Multimeter

Best HVAC Multimeter - Fluke 116 Digital HVAC Multimeter

The Fluke 116 Digital HVAC Multimeter is a compact, True-RMS digital multimeter designed specifically for HVAC professionals. It offers accurate measurements of voltage, current, resistance, capacitance, frequency, and temperature, along with microamp measurements for testing flame sensors. The multimeter also features a built-in thermometer for HVAC applications and a low input impedance to help prevent false readings due to ghost voltage..

  • Detail
  • Special Features
  • Specification

The Fluke 116 is engineered to meet the demanding needs of HVAC professionals. Its True-RMS capability ensures accurate readings even for distorted waveforms, making it ideal for troubleshooting complex HVAC systems. The microamp measurement feature allows users to test flame sensors, which is essential for diagnosing issues in heating systems. The built-in thermometer eliminates the need for a separate temperature probe, streamlining the troubleshooting process. With its low input impedance, the Fluke 116 helps prevent false readings caused by ghost voltages, ensuring reliable diagnostics. The large white LED backlight enhances visibility in dimly lit areas, while the Min/Max/Average recording feature aids in capturing and analyzing signal fluctuations. Its compact and ergonomic design allows for easy one-handed operation, and the CAT III 600 V safety rating ensures safe use in industrial settings.

  • True-RMS Measurement: Ensures accurate readings for non-linear loads.

  • Microamp Measurement: Allows testing of flame sensors.

  • Built-in Thermometer: Measures temperature from -40°C to 400°C (-40°F to 752°F).

  • Low Input Impedance (LoZ): Helps prevent false readings due to ghost voltage.

  • Large White LED Backlight: Provides visibility in poorly lit areas.

  • Min/Max/Average Recording: Captures signal fluctuations over time.

  • Compact Ergonomic Design: Facilitates one-handed operation.

  • CAT III 600 V Safety Rating: Ensures safe operation in industrial environments

Measurement Range / Resolution Accuracy
DC Voltage 6.000 V, 60.00 V, 600.0 V ±(0.5% + 2)
AC Voltage 6.000 V, 60.00 V, 600.0 V ±(1.0% + 3)
DC Current 600.0 µA ±(1.0% + 2)
AC Current 600.0 µA ±(1.5% + 3)
Resistance 600.0 Ω to 40.00 MΩ ±(0.9% + 1)
Capacitance 1000 nF to 1000 µF ±(0.9% + 2)
Frequency 99.99 Hz to 50.00 kHz ±(0.1% + 2)
Temperature -40°C to 400°C ±(1.0% + 10)
Microamps (AC/DC) 600.0 µA ±(1.0% + 2)
Display 6000 counts -
Battery Life 400 hours (without backlight) -
Safety Rating CAT III 600 V -
Ingress Protection IP54 -
